Product Name: | Digital Conductivity Sensor | Principle: | Four-electrode |
---|---|---|---|
Accuracy: | ±1% | Resolution: | 1uS/cm |
Power Supply: | DC 6~12V, Current <50mA | Output Signal: | Support RS-485, MODBUS Protocol |
Material: | SS316 PEEK | Customized Support: | OEM, ODM, OBM |
High Light: | Water Ec Sensor Fertility Detection,Water Ec Sensor Four Electrode,water quality probe Four Electrode |
Water conductivity sensor Water fertility detection EC meter agricultural species plant network equipment
Digital conductivity sensor adopts a new generation of four-electrode/six-electrode technology, with wide measurement range, automatic switching measurement range, built-in temperature sensor and real-time temperature compensation. It has excellent anti-pollution ability and will not cause polarization even in the harsh environment for long-term online monitoring. RS485 output, can be networked without a controller.We launched a wireless water quality monitoring solution based on the current rapid development of the Internet of Things technology, combining smart terminals and traditional display units through wireless transmission to achieve real-time dynamic water quality monitoring functions such as data cloud display, remote cloud control, and upper and lower limit alarms.
Check whether the electrode or light window of the sensor is dirty, whether the cleaning brush is normal, and whether the electrode is normal.
Check whether the cleaning brush (if any) of the sensor is damaged and whether it can work normally.
Continuous use for more than 18 months, (as the case may be) return to the factory to replace the dynamic sealing device
Product name
|
Four-electrode conductivity sensor
|
Six-electrode conductivity sensor
|
||
Model
|
DSC480
|
DST481
|
DST482
|
|
Range
|
1uS/cm~200 mS/cm
|
1uS/cm~100 mS/cm
|
1uS/cm~100 mS/cm
|
|
Conductance accuracy
|
±1%
|
|||
Resolution
|
1uS/cm
|
|||
Response time
|
<2 sec
|
|||
Protection level
|
IP68
|
|||
Max operating pressure
|
6 bar
|
|||
Temperature range
|
0~ 50°C
|
|||
Sensor interface
|
Support RS-485, MODBUS protocol
|
|||
Installation
|
Input type
|
|||
Power supply
|
DC 6~12V, current <50mA
|
|||
Temperature Sensor
|
NTC
|
|||
Electrode material
|
Nickel
|
|||
Housing material
|
PEEK
|
|||
Probe cable length
|
5 meters (default), can be customized
|
|||
Size
|
Φ 22 *165mm
|
|||
Calibration
|
One or two point calibration
|
* Standardized workshop and process
* Strict professional quality inspection
* Return is supported if the product is unqualified
* Fast delivery
* Warranty for 1 year
Q: Is your company a manufacturer??
A: Yes,we are a professional manufacturer of online water quality monitoring products: oil in water sensor/ DO sensor/ NH4-N sensor / ORP / COD sensor / Blue-green algae sensor /Conductivity sensor /TDS / TSS /MLSS,ect.
Q: What parameters do you need for product selection?
A: Application, Range, Power supply and Output signal.
Q: How about the quality of the managements?
A: We have a complete quality control system, our products will be fully pre-inspection before shipping to you. We have the certification of ISO, CE, we could send the certification test of our company to you.
Q: Can you offer OEM services?
A: Yes,we support OEM and ODM products according to your requirements.
Q: What are your terms of payment and delivery time?
A: We could accept T/T, Paypal, Western Union, Credit Assurance. Generally, we will arrange the shipment within 7 days after received payment.
Q: How about warranty?
A: 12 months warranty
