| Place of Origin: | China |
|---|---|
| Brand Name: | Desun Uniwill |
| Model Number: | DST420 |
| Minimum Order Quantity: | 1 |
| Price: | Determined by the number of specific orders |
| Packaging Details: | Carton packaging |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 1000 |
| Product Name: | Online Turbidity Sensor | Range: | 0-4000NTU |
|---|---|---|---|
| Accuracy: | ＜5% | Resolution: | 0.1NTU |
| Response Time: | ＜5 Sec | Sensor Interface: | Support RS-485, MODBUS Protocol |
| Power Supply: | DC 6~12V, Current <50mA (when Not Cleaned) | Method: | 90° Scattered Light |
| Cleaning System: | Have | Probe Cable Length: | 5 Meters (default), Can Be Customized |
| Material: | POM/SS316 | ||
| High Light: | Customized Water Turbidity Sensor,12V Water Turbidity Sensor,SS316 Online Turbidity Meter |
||
High Turbidity Data acquisition terminal online turbidity meter water quality analyzer manufacturers
|
Product Name
|
Online Turbidity Sensor
|
Self-cleaning Turbidity Sensor
|
|
Model
|
DST410
|
DST420
|
|
Principle
|
90° scattered light
|
|
|
Measuring Range
|
0~4000NTU
|
|
|
Accuracy
|
±5%
|
|
|
Resolution
|
0.1NTU
|
|
| Max working pressure | 10 meters | |
|
Output signal
|
Support RS-485, MODBUS protocol
|
|
|
Power information
|
DC 6~12V, current <50mA (when not cleaned)
|
|
|
Size
|
Φ45*175.8 mm
|
Φ32*161mm
|
|
Housing material
|
SS316
|
|
|
Cable length
|
5 meters (default), can be customized
|
|
|
Optical window
|
Have
|
|
|
Self-cleaning system
|
No
|
Have
|
Before installation, please check the appearance of the cables for damage, and disperse the cables.
1. When using the throw-in sensor, avoid the sensor hitting the wall or other facilities caused by water flow. If the water flow rate is too fast, the sensor must be fixed.
2. There should be no obstructions in front of the measurement. For example, fluorescence sensors should be avoided from light.
3. The water depth position where the sensor is installed should not exceed 2 meters from the horizontal, and the installation should be based on the fluctuation of the water flow. The water depth of the location should not be less than 30 cm. (Adjustable according to the measured water body)
4. The sensor should be installed in a location where there is no air bubbles to prevent air bubbles from affecting the measurement data of the sensor.
5. Do not use the sensor's own cable to hoist the sensor, and install a cable protection device to prevent excessive tension between the cable and the sensor, causing the cable to break.
6. The sensor should not be installed with the measuring side facing upwards, it can be installed vertically downwards or horizontally.
7. If you use this product in the water diversion tank, please consult the company's sales staff to confirm the specific installation requirements.
The turbidity sensor provided by our company has a one-year warranty from the date of delivery, and the repaired or replaced product will only enjoy the remaining warranty period. After receiving the product quality problem provided by the customer, our company will confirm whether the product needs repair within 24 hours; if the repair permit is not obtained, the user must not send the product back without authorization.
The supplier guarantees that the products supplied meet the statutory quality standards, and are responsible for the quality of the products, and that the product packaging and registered trademarks are in compliance with the relevant national regulations.
Q: Is your company a manufacturer??
A: Yes,we are a professional manufacturer of online water quality monitoring products: oil in water sensor/ DO sensor/ NH4-N sensor / ORP / COD sensor / Blue-green algae sensor /Conductivity sensor /TDS / TSS /MLSS,ect.
Q: Can you offer OEM services?
A: Yes,we support OEM and ODM products according to your requirements.
Q: What are your terms of payment and delivery time?
A: We could accept T/T, Paypal, Western Union, Credit Assurance. Generally, we will arrange the shipment within 7 days after received payment.
Q: How about warranty?
A: 12 months warranty.
