| Place of Origin: | China |
|---|---|
| Brand Name: | Desun Uniwill |
| Certification: | CE |
| Model Number: | DS430 |
| Minimum Order Quantity: | 0-100PCS |
| Price: | According to the specific quantity |
| Packaging Details: | carton packaging |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Product Name: | Fiber Optic Chlorophyll Sensor | Principle: | Fluorescence Method |
|---|---|---|---|
| Measure Range: | 0-400 Ug/L | Resolution: | 0.1ug/l |
| Housing Material: | SS316 | Power Supply: | 5~12vdc,current <50mA (when Not Cleaned) |
| Output Signal: | RS485, MODBUS Protocol | IP Grade: | IP68 |
| Deepest Depth: | Underwater 10 Meters | ||
| High Light: | Chlorophyll Sensor With Automatic Cleaning Brush,Underwater Testing Chlorophyll Sensor,Online Fiber Optic Chlorophyll Probe |
||
The fiber-optic chlorophyll sensor adopts the principle of the fluorescence method. According to the spectral absorption characteristics of chlorophyll a, the water body is irradiated by a high-energy LED light source, and the chlorophyll a in the water body is excited to generate fluorescence of a specific wavelength, and the concentration of chlorophyll a in the water is measured. The sensor's fiber-optic structure provides excellent repeatability and stability and is less susceptible to ambient light. With automatic cleaning, the brush eliminates air bubbles, reduces the impact of contamination on the measurement, makes the maintenance cycle longer, and maintains excellent stability for long-term online use.
