Place of Origin: | China |
---|---|
Brand Name: | Desun Uniwill |
Certification: | CE |
Model Number: | DS-380 |
Minimum Order Quantity: | 0~100 pcs |
Price: | $280.00 - $400.00/ Piece |
Packaging Details: | Carton packaging |
Delivery Time: | 7~ 15 working days |
Payment Terms: | L/C, D/A, D/P, T/T |
Supply Ability: | 0~1000 pcs |
Model: | DS380 | Principle: | Optical |
---|---|---|---|
Measuring Range: | 0~20mg/L Or 0-200% Saturation | Response Time: | 3 Seconds |
Accuracy: | 1% | Protection Level: | IP68 |
Installation: | Submersible | Temperature Sensor: | NTC |
Temperature Range: | 0~50°C | Temperature Accuracy: | ±0.2°C |
Output: | RS-485, MODBUS Protocol | Power Supply: | DC 6~12V, Current <50mA |
Size: | Φ26*155 Mm | Cable Length: | Default 5 M |
Housing Material: | SS316/Titanium Alloy | ||
High Light: | Autoclave Dissolved Oxygen Sensor,20ma Optical Dissolved Oxygen Sensor,Fermentation Optical Dissolved Oxygen Probe |
1. Feature
Digital sensor, RS-485 output, support MODBUS. Optional automatic cleaning brush to eliminate the impact of oil on the measurement, this product uses a unique optical and electronic filtering technology to eliminate the impact of ambient light on the measurement, not affected by suspended solids.
2. Application
The fluorescence dissolved oxygen sensor uses a new generation of fluorescence lifetime technology. we independently develop high performance fluorescent materials. No anaerobic consumption, no flow restrictions, no electricity required. The solution requires no maintenance and calibration, no hydrogen sulphide, and excellent stability. Built-in temperature sensor and automatic temperature compensation. The RS485 output is suitable for networks without a controller.
Item | Parameters |
Model | DS380 |
Principle | Fluorescence analysis method |
Measuring range | 0~20mg/L or 0-200% saturation |
Response time | 3 sec |
Accuracy | 1% |
Protection level | IP68 |
Installation | Submersible |
Temperature sensor | NTC |
Temperature range | 0~50°C |
Temperature accuracy | ±0.2°C |
Output | Support RS-485, MODBUS protocol |
Power supply | DC 6~12V, current <50mA |
Size | Φ26*155 mm |
Probe cable length | Default 5 m, customized 10m, 15 m and 30 m cable |
Fluorescent cap life | 1 year |
Maximum working pressure | 3bar |
Housing material | SS316/Titanium alloy |
